- 8× 10/100 Mbps RJ45 Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port
- 8× PoE+ ports transfer data and power on individual cables
- Works with IEEE 802.3af/at compliant PDs
- Supports PoE Power up to 30W for each PoE port
- Supports PoE Power up to 124W for 8 PoE ports
- Up to 250m data and power transmitting range under Extend Mode
- Isolation Mode allows one-click client traffic separation for higher security and performance
- PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
- Fanless Design reduces power consumption and works silently in its location
- Plug and play with no configuration required
Đặc tính kỹ thuật
HARDWARE FEATURES |
Interface |
8× 10/100 Mbps 802.3af/at PoE+ Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port
AUTO Negotiation
AUTO MDI/MDIX |
Network Media |
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m) |
Fan Quantity |
Fanless |
Physical Security Lock |
Yes |
External Power Supply |
External Power Adapter (Output: 53.5VDC / 2.43A) |
Packet Forwarding Rate |
5.6544 Mpps |
PoE Ports (RJ45) |
Standard: 802.3 af/at compliant
PoE Ports: Ports 1–8
Power Supply: 124 W |
Mac Address Table |
2K |
Jumbo Frame |
16 KB |
Switching Capacity |
7.6 Gbps |
Dimensions (W x D x H) |
8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm) |
Max Power Consumption |
5.95 W (220/50 Hz. no PD connected)
140.92 W (220/50 Hz. with 124 W PD connected) |
Max Heat Dissipation |
20.29 BTU/h (no PD connected)
480.54 BTU/h (220/50 Hz. with 124 W PD connected) |
SOFTWARE FEATURES |
Transmission Method |
Store-And-Forward |
Advanced Functions |
Compatible With IEEE 802.3af/at Compliant PDs
Extend Mode Button (Ports 1–4 and Ports 1–8, Up to 250 m PoE power supply and data transmission)
Isolation Mode Button (Ports 1–8)
PoE Auto Recovery Button (Ports 1–8)
Mac Address Auto-Learning and Auto-Aging
IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode |
OTHERS |
Certification |
FCC, CE, RoHS |
Environment |
Operating Temperature: 0–40 ℃ (32–104 ℉)
Storage Temperature: -40–70 ℃ (-40–158 ℉)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing |
- Bảo hành: 36 tháng.
