Wireless Basic Specification |
Radio |
Dual-stream Dual-band |
Protocol |
Wi-Fi 5 (IEEE 802.11ac Wave 2/Wave1)
Wi-Fi 4 (IEEE 802.11n)
802.11a/b/g |
Operating Bands |
802.11b/g/n: 2.4 GHz ~ 2.4835 GHz
802.11a/n/ac: 5.150 GHz ~ 5.350 GHz, 5.725 GHz ~ 5.850 GHz
Country-specific restriction apply.
Egypt:
802.11b/g/n: 2.4 GHz ~ 2.4835 GHz
802.11a/n/ac: 5.150 GHz ~ 5.350 GHz |
Antenna |
Built-in Omnidirectional Antennas (2.4 GHz: 3dBi, 5 GHz: 4dBi) |
Spatial Streams |
2.4 GHz: 2x2 MIMO
5 GHz: 2x2 MIMO |
Max Throughput Rate |
Up to 400 Mbps at 2.4 GHz
Up to 867 Mbps at 5 GHz
1.267 Gbps per AP |
Maximum Wi-Fi Clients |
110 |
Recommended Wi-Fi Clients |
80 |
Modulation |
OFDM: BPSK@6/9 Mbps, QPSK@12/18 Mbps, 16-QAM@24 Mbps, 64-QAM@48/54 Mbps
DSSS: DBPSK@1 Mbps, DQPSK@2 Mbps, and CCK@5.5/11 Mbps
MIMOOFDM: BPSK, QPSK, 16QAM, 64QAM and 256QAM |
Receive Sensitivity |
11b: -91 dBm (1 Mbps), -88 dBm (5 Mbps), -85 dBm (11 Mbps)
11a/g: -89 dBm (6 Mbps), -80 dBm (24 Mbps), -76 dBm (36 Mbps), -71 dBm (54 Mbps)
11n: -83 dBm@MCS0, -65 dBm@MCS7, -83 dBm@MCS8, -65 dBm@MCS15
11ac HT20: -83 dBm (MCS0), -57 dBm (MCS9)
11ac HT40: -79 dBm (MCS0), -57 dBm (MCS9)
11ac HT80: -76 dBm (MCS0), -51 dBm (MCS9) |
Wireless Basic Specification |
Maximum Transmit Power |
EIRP
≤ 32 dBm (2.4GHz)
≤ 32 dBm (5GHz)
country-specific restrictions apply.
Myanmar:
2400~2483.5MHz ≤ 20dBm
5150~5350MHz ≤ 23dBm
5470~5850MHz ≤ 25dBm
Thailand:
2400 MHz~2483.5 MHz ≤ 20 dBm
5150 MHz~5350 MHz ≤ 23 dBm
5470 MHz~5725 MHz ≤ 25 dBm
5725 MHz~5850 MHz ≤ 30 dBm
Egypt:
5.150 GHz ~ 5.350 GHz: ≤20 dBm (EIRP)
2.4 GHz ~ 2.4835 GHz: ≤20 dBm (EIRP) |
Router Basic Specification |
Fixed WAN Port |
1 × 10/100/1000 Base-T |
Fixed LAN Port(s) |
1 × 10/100/1000 Base-T |
LAN/WAN Switchable Port(s) |
3 × 10/100/1000 Base-T |
Performance |
600 Mbps (1500Byte, NAT+Flow Audit are enabled)
300 Mbps (1500Byte, NAT+Authentication, Applicaation Identification, Flow Audit and Flow Control are enabled) |
Recommended Total Clients |
150 |
Power Consumption |
≤ 15 W |
System |
CPU |
2 Cores, 880 MHz |
SDRAM/RAM |
256 MB |
Flash Memory |
32 MB SPI NOR FLASH |
Hardware Feature |
Power Supplies |
DC 12V/1.5A |
DC Port Dimensions |
Outer Diameter: 5.5 mm
Inner Diameter: 2.1 mm
Length: 10 mm
(Outer Diameter: 0.22 in.
Inner Diameter: 0.08 in.
Length: 0.39 in. ) |
Indicator |
1 × system LED indicator
3 × Mesh LED indicator |
Buttons |
1 × Reset button
1 × Mesh button |
Dimensions(W × D × H) |
120 mm × 120 mm × 28 mm (without mounting plate) |
Weight |
0.251 kg (without mounting plate) |
Installation |
Desk-mount /Wall-mount |
MTBF |
> 400000 Hours |
Operating Temperature |
0°C to 40°C (32°F to 104°F) |
Storage Temperature |
-40°C to 70°C (-40°F to 158°F) |
Operating Humidity |
5% to 95% Noncondensing |
Storage Humidity |
5% to 95% Noncondensing |
Port Surge |
4kV |
IP(Ingress Protection) |
IP30 |
