- Centralized cloud-based management, with intuitive web and app-based interface.
- Wi-Fi 6 ready: delivers greater network efficiency and lower latency, with nearly four times the capacity of previous Wi-Fi standards.
- 4 x 4 MU-MIMO slices through congestion, reducing wait time for all users.
- Superior throughput with dual-band transfer speeds of up to 1147 Mbps in the 2.4 GHz band and 2402 Mbps in the 5 GHz band.
- Coverage is shared more efficiently over more users with Airtime Fairness.
- Band Steering intelligently manages users, pushing them onto the higher radio frequency when possible.
- Two LAN ports capable of Link Aggregation offer 3.5 Gbps of backhaul up to the wired network, eliminating bottlenecks at the AP.
- Support for Power over Ethernet 802.3at means less wires, for cleaner and easier deployment.
- With Zero Touch Deployment, swift plug and play installation eliminates the need for on-site setup.
- Supports WPA3™ - the latest Wi-Fi encryption standard for even more protection.
- PoE Injector and Power Adapter are not included.
Specifications
Model |
DBA-X2830P |
General |
Interface |
IEEE 802.11ax Wi-Fi 6
IEEE 802.11a/b/g/n/ac Wave 2 wireless
1 x 10/100/1000/2500 Mbps Ethernet Port
1 x 10/100/1000 Mbps Ethernet Port
1 x RJ45 Console port |
Standards |
IEEE 802.11a/b/n/g/ac/ax
IEEE 802.3az Energy-Efficient Ethernet (EEE)
IEEE 802.3at Power over Ethernet (PoE)
IEEE 802.3i/u/ab
IEEE 802.3x Flow Control |
LEDs |
Power/Cloud, 2.4 GHz, 5 GHz, LAN 1 (PoE), LAN 2 |
Data Signal Rate |
2.4 GHz: Up to 1147 Mbps
5 GHz: Up to 2402 Mbps |
Antenna |
4 x 4 Internal omni-directional antennas
(2.4 GHz: 3 dBi, 5 GHz: 4 dBi) |
Maximum Output Power |
2.4 GHz: 29 dBm
5 GHz: 28 dBm |
Functionality |
Security |
WPA2/WPA3 Personal/Enterprise
MAC address filtering
RADIUS server authentication
SSID isolation
Guest isolation
Captive portal
Station isolation |
Maximum SSIDs |
Supports up to 16 SSIDs per device - Up to 8 SSIDs per wireless band |
Physical |
Power Input |
IEEE 802.3at Power over Ethernet (PoE)
Power Adapter : 12V/ 2.5A |
Power Consumption |
PoE: 25.1 W
Power adapter: 27 W |
Dimensions |
224.5 x 223.9 x 50 mm |
Weight |
935 g |
Operating Temperature |
0 to 40 °C |
Storage Temperature |
-20 to 65 °C |
Operating Humidity |
10% ~ 95% RH |
Storage Humidity |
5% ~ 95% RH |
