- Easy to manage with D-Link’s free management software-based solution, Nuclias Connect
- Superior throughput with tri-band transfer speeds up to 400 Mbps in the 2.4 GHz band and 866 Mbps in the 5 GHz bands
- IEEE 802.11a/b/g/n/ac Wave 2 wireless
- 1 x Gigabit LAN port for high-capacity backhaul to the wired network
- Supports Power over Ethernet (802.3at) for simpler installation with less cable clutter
- Supports WPA2™ - Wi-Fi security for more protection
- Supports multiple VLANs for enhanced network management and up to 16 SSID setups
- Quality of Service (QoS) prioritizes time-sensitive traffic for a smoother Wi-Fi experience
- Supports multiple AP modes to ensure optimization based on your network’s needs
- PoE Injector and Power Adapter Not Included.
Specifications
Model |
DAP-2720 |
General |
Device Interfaces |
1 x IEEE 802.11a/b/g/n/ac Wave 2 wireless
1 x 10/100/1000 Mbps Gigabit LAN (supports PoE) |
Standards |
IEEE 802.11a/b/g/n/ac
IEEE 802.3/u/ab/x/az
IEEE 802.3az Energy-Efficient Ethernet (EEE)
IEEE 802.3at Power over Ethernet |
Antennas |
6 x Internal Antennas |
LEDs |
Power/Status |
Operating Frequency |
2.4 GHz band: 2.4 to 2.4835 GHz
5 GHz band: 5.15 to 5.35 GHz, 5.47 to 5.825 GHz |
Maximum Output Power |
2.4 GHz band: 26 dBm
5 GHz band: 24 dBm |
Data Signal Rate |
2.4 GHz band: Up to 400 Mbps
5 GHz band: Up to 866 Mbps per band |
Functionality |
Network Management |
D-Link Nuclias Connect
Telnet
Secure Telnet (SSH)
Web (HTTP)
Secure Socket Layer (SSL)
Traffic control
SNMP v1/v2c/v3 |
Security |
128-bit personal wireless encryption
128-bit enterprise wireless encryption
WEP 64/128-bit encryption
SSID Broadcast Disable
MAC Address Access Control
Network Access Protection (NAP)
Internal RADIUS Server |
Physical |
Power Supply |
External Power Adapter: 12V / 2.5A
IEEE 802.3at PoE |
Max. Power Consumption |
Adapter Mode: 15.74 W
PoE Mode: 16.08 W |
MTBF |
> 30,000 hours |
Operating Temperature |
0°C to 40°C |
Storage Temperature |
-20°C to 65°C |
Operating Humidity |
10% to 90% |
Storage Humidity |
5% to 95% |
Weight |
721.8 g |
Dimensions |
212.4 x 212.4 x 47.7 mm |
- Bảo hành: 2 năm.
