- Easy to manage with D-Link’s free centralized management software-based solution Nuclias Connect
- Superior throughput with dual-band transfer speeds up to 600Mbps in the 2.4GHz band and 1700Mbps in the 5GHz band
- Band Steering makes sure connected devices get the best available and supported frequency band
- Supports Power over Ethernet (802.3at) for simpler installation with less cable clutter
- Simple, soft-edge design, ideal for subtle visibility when wall or ceiling mounted (mounting hardware included)
- Supports multiple VLANs for enhanced network management and up to 16 SSID setups
- Supports WPA2™ - WiFi security for more protection
- 2 x Gigabit LAN port for high-capacity backhaul to the wired network
- Supports multiple AP modes to ensure performance optimization based on your network’s needs
- MAC Address Filtering and WLAN Partitioning ensure ultimate control of your network’s access
- Captive Portal with industry-standard authentication for enhanced access management
- Works as a standalone AP or as part of a centralized, scalable multi-device deployment
Đặc tính kỹ thuật
Model |
DAP-2682 |
General |
Device Interfaces |
802.11a/b/g/n/ac Wave 2 wireless
2 Gigabit LAN port (PoE supported) |
Standards |
IEEE 802.11a/b/g/n/ac
IEEE 802.3u/ab
IEEE 802.3az Energy-Efficient Ethernet (EEE)
IEEE 802.3af Power over Ethernet |
Wireless Frequency Range |
2.4 GHz band: 2.4 GHz to 2.4835 GHz
5 GHz band: 5.15 to 5.35 GHz, 5.47 to 5.85 GHz |
Antennas |
4 x internal dual-band antennas |
Antennas Gain |
3.7 dBi for 2.4 GHz
4.8 dBi for 5 GHz |
Maximum Output Power |
ETSI: 16 dbm for 2.4GHz
ETSI: 24 dbm for 5GHz |
Data Signal Rate |
2.4 GHz band: Up to 600Mbps
5 GHz band: Up to 1700Mbps |
Functionality |
Security |
The latest 128-bit personal/ enterprise wireless encryption
WEP 64/128-bit encryption
SSID broadcast disable
MAC address access control
Internal RADIUS serverWPA-Personal
WPA-Enterprise
WPA2-Personal
WPA2-Enterprise
WEP 64/128-bit encryption
SSID broadcast disable
MAC address access control
Internal RADIUS server |
Network Management |
Telnet
Secure Telnet (SSH)
Web (HTTP)
Secure Socket Layer (SSL)
Traffic control
Nuclias Connect Software
Nuclias Connect Hub |
LEDs |
Power/status |
Physical |
Dimensions |
190 x 190 x 43.7 mm |
Weight |
551.6 g without mounting bracket |
Power Supply |
12V/ 2.5A (power adapter not included)
802.3at PoE |
Maximum Power Consumption |
15.5 W |
MTBF |
341,897 hours |
Temperature |
Operating: 0 to 40 °C
Storage: -20 to 65 °C |
Humidity |
Operating: 10% to 90% non-condensing
Storage: 5% to 95% non-condensing |
- Bảo hành: 2 năm.
