Designed for Remote Office or Small Office: Supports one of the tunnel type; 20× LAN-to-LAN IPsec, 16× OpenVPN, 16× L2TP, and 16× PPTP VPN connections.
- Reliable and Flexible: Up to 4 WAN connections connecting to 4 different Internet service providers and private links. Bandwidth based, app-based, or automatic line backup allow flexible and reliable use of your wide-area links.
- Gigabit Router: All (5) gigabit connecting ports provide high-speed wired connectivity.
- Built-in Firewall: Built-in firewall and ACS filtering for easy penetration and blocking settings
- VLAN and VLAN routing: Works with standard 802.1Q switches for multiple subnet separation and communication. Multi-Nets NAT for direct Internet access from any VLAN.
- Secured Router: Advanced ACS policies, DoS defense, IP/MAC/URL filtering, and more security functions protect your network and data.
- Centralized Management: Work with center control Omada SDN controller enables cloud access for easy management and deployment.
- Omada Cloud-based SDN: Zero-Touch Provisioning (ZTP) eliminates the installation and maintenance truckloads.
Đặc tính kỹ thuật
HARDWARE FEATURES |
Standards and Protocols |
IEEE 802.3, 802.3u, 802.3ab, IEEE 802.3x, IEEE 802.1q
TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP |
Interface |
1 Fixed Gigabit WAN Port
1 Fixed Gigabit LAN Port
3 Changeable Gigabit WAN/LAN Ports |
Button |
Reset Button |
Power Supply |
External 9V/0.9A DC Adapter |
Flash |
SPI 16MB |
DRAM |
128 MB |
LED |
PWR, SYS, WAN, LAN |
Dimensions (W x D x H) |
158 × 101 × 25 mm |
PERFORMANCE |
Concurrent Session |
25 |
IPsec VPN Throughput |
41.5 Mbps (EAP-SHA1-AES256) |
BASIC FUNCTIONS |
WAN Connection Type |
Static/Dynamic IP
PPPoE
PPTP
L2TP |
DHCP |
DHCP Server/Client
DHCP Address Reservation
Multi-net DHCP
Multi-IP Interfaces |
MAC Clone |
Modify WAN MAC Address |
IPTV |
IGMP v2/v3 Proxy |
VLAN |
802.1Q VLAN |
ADVANCED FUNCTIONS |
ACL |
IP/Port/Protocol/Domain Name Filtering |
Advanced Routing |
Static Routing
Policy Routing |
Bandwidth Control |
IP or Port-based Bandwidth Control
Guarantee & Limited Bandwidth |
Load Balance |
Intelligent Load Balance
Application Optimized Routing
Link Backup (Timing, Failover)
Online Detection |
NAT |
One-to-One NAT
Multi-Net NAT
Virtual Server
Port Triggering
NAT-DMZ
FTP/H.323/SIP/IPSec/PPTP ALG, UPnP |
Security |
SPI Firewall
VPN Passthrough
DoS Defence, Ping of Death
Local Management |
Session Limit |
IP-based Session Limit |
VPN |
IPsec VPN |
20 IPsec VPN Tunnels
LAN-to-LAN or Client-to-LAN
Main, Aggressive Negotiation Mode
DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
IKEv1/v2
MD5, SHA1 Authentication Algorithm
NAT Traversal (NAT-T)
Dead Peer Detection (DPD)
Perfect Forward Secrecy (PFS) |
PPTP VPN |
PPTP with MPPE Encryption
PPTP VPN Server or Clients for (10 clients) |
L2TP VPN |
L2TP over IPSec
L2TP VPN Server or Clients (10 clients) |
OpenVPN |
OpenVPN Server or Client (for 10 clients) |
SECURITY |
Attack Defense |
TCP/UDP/ICMP Flood Defense
Block TCP Scan (Stealth FIN/Xmas/Null)
Block Ping from WAN |
Filtering |
WEB Group Filtering
URL Filtering
Web Security |
ARP Inspection |
Sending GARP Packets
ARP Scanning
IP-MAC Binding |
Access Control |
Source and Destination IP Access Control |
AUTHENTICATION |
Web Authentication |
Captive web portal authentication styles
• No Authentication
• Simple Password
• Hotspot (Local User / Voucher / SMS / Radius)
• External Radius Sever
• External Portal Sever
• Facebook |
MANAGEMENT |
Omada App |
Yes |
Centralized Management |
Omada Cloud-Based Controller
Omada Hardware Controller (OC200, OC300)
Omada Software Controller |
Service |
Dynamic DNS (Dyndns, No-IP) |
Cloud Access |
Cloud access through Omada SDN controllers |
Maintenance |
Time Setting
Diagnostic
Firmware Upgrade
Factory Defaults/Reboot
Backup&Restore
System Log
Remote Management
Statistics
Controller Settings
SNMP |
Management Features |
Automatic Device Discovery
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
Captive Portal Configuration
ZTP (Zero-Touch Provisioning) |
- Bảo hành: 36 tháng.
