High-Speed Connectivity
- 802.11ac wireless specification delivers blazing fast wireless connectivity with increased range and reliability
- 10/100/1000 Gigabit Ethernet WAN port for speedy Internet access
- Four 10/100/1000 Gigabit Ethernet LAN ports give you high-speed wired connectivity
Flexible Bandwidth
- Concurrent dual-band wireless for connections up to 1200 Mbps
- Supports MU-MIMO (AC Wave II)
- Supports Bandwidth Control
Setup and Management
- Web browser-based setup and configuration
- Simple & Easy quick setup interface to guide you through the con¬guration process
- Firewall and access control options to prevent attacks and restrict access to your network
Specifications
Model |
DIR-1253 |
General |
Device Interfaces |
IEEE 802.11 ac/n/g/b/a wireless LAN
10/100/1000Gigabit Ethernet WAN port
Four 10/100/1000Gigabit Ethernet LAN ports |
LEDs |
Power
Internet
2.4GHz
5GHz
LAN (x4)
WAN |
Antenna Type |
Four external High Gain 5dBi antennas
Supports Beamforming |
Functionality |
Security |
WPA &WPA2 (Wi-Fi Protected Access)
WPS (Wi-Fi Protected Setup) |
Advanced Features |
Web quick setup
DMZ (Demilitarized Zone)
WAN VLAN
UPNP
Bandwidth Control
Firewall - Network Address Translation (NAT)
Multiple SSID
IPv6 ready
Static Route |
Physical |
Dimensions |
270 x 139 x 29 mm |
Weight |
288g |
Power Adaptor |
Input: 100 to 240V AC, 50/60Hz
Output: 12V, 1 A |
Temperature |
Operating: 0 to 40 °C (32 to 104 °F)
Storage: -20 to 65 °C (-4 to 149 °F) |
Humidity |
Operating: 10% to 90% non-condensing
Storage: 5% to 95% non-condensing |
- Bảo hành: 24 tháng.
