- 802.11ac Wave 2, Dual-Band, up to 2.5 Gbps
- 4 Internal Omnidirectional Antennas
- Up to 64 dynamic VLANs per access point
- 802.11k Fast Roaming, MU-MIMO and QoS with WMM
- Wireless Encryption including WPA/WPA2 Personal, WPA/WPA2 Enterprise, MAC address filtering and Rogue AP detection
- Link Aggregation
Specifications
Model |
DWL-8620AP |
General |
Hardware Version |
A1 |
Wireless Interface |
IEEE 802.11b/g/n 2.4 GHz wireless
IEEE 802.11/a/n/ac Wave 2 5 GHz wireless |
Ethernet Interface |
2 x 10/100/1000BASE-T LAN port |
Console Port |
RJ45 |
MIMO |
4 x 4 |
Data Rate |
2.4 GHz - Up to 800 Mbps
5 GHz - Up to 1733 Mbps |
Antenna |
Internal omni-directional antennas
2.4 GHz: 3 dBi
5 GHz: 4 dBi |
Operating Frequency |
2400 to 2483.5 MHz
5150 to 5850 MHz |
Operating Channels |
1 to 13 channels for 2.4 GHz band (per country code)
36 to 165 channels for 5 GHz band (per country code) |
System Management |
Web-based user interface (HTTP/HTTPs)
Command-Line Interface (CLI)
Telnet/SSH |
Functionality |
Advanced Features |
Auto Channel selection
802.1p Quality of Service (QoS)
Wireless Multimedia (WMM)
Wireless Distribution System (WDS)
Band steering
Airtime Fairness
Link Aggregation
IEEE 802.11kvr Fast Roaming |
Management |
Operating Mode |
Standalone mode
Managed mode - Centrally managed by D-Link Wireless Controller |
Management Interfaces |
Web-based User Interface (Web UI)
Telnet/SSH
Command Line Interface (CLI)
SNMP v1/v2c/v3 |
Security |
SSID Security |
Up to 32 SSIDs, 16 per radio
802.1Q VLAN
Station Isolation |
Wireless Security |
Latest 128-bit Personal wireless encryption
Latest 192-bit Enterprise wireless encryption
SAE
OWE (Enhanced Open)
AES
TKIP |
Detection & Prevention |
Rogue and Valid AP Classification |
Authentication |
MAC address filtering |
Physical |
Power Supply |
External power adapter: 12 V DC 2.5 A
Supports 802.3at PoE PD on LAN 1 Port |
Power over Ethernet |
802.3at |
Max Power Consumption |
24.24 W |
Dimensions |
220 x 47 mm |
Weight |
0.79 kg without bracket |
Operating Temperature |
0 to 40 °C |
Storage Temperature |
-20 to 65 °C |
Operating Humidity |
10% to 90% non-condensing |
Storage Humidity |
5% to 95% non-condensing |
