Máy chiếu gần EPSON EB-530
SHORT-THROW PROJECTOR
- Công nghệ: 3LCD.
- Cường độ sáng: 3.200 Ansi Lumens.
- Độ phân giải thực: XGA (1,024 x 768).
- Độ tương phản: 16,000:1.
- Độ phóng to hình ảnh: 50 - 108 inch (0.54 - 1.22m) (Zoom: Wide), 37 - 80 inch (0.54 - 1.22m) (Zoom: Tele).
- Bóng đèn: 215W UHE, tuổi thọ 10,000 giờ.
- Chỉnh lệch hình: +/- 15º dọc, +/- 15º ngang.
- Loa âm thanh: 16W.
- Hỗ trợ kết nối: USB type A, USB type B, HDMI, RS232 control.
- Khởi động trong 7 giây và tắt máy nhanh (Quick start and instant off).
- Trình chiếu hình ảnh trực tiếp từ USB.
- Trình chiếu không dây (Wireless LAN) (Option Wireless Card).
- Điều khiển máy chiếu qua mạng LAN (cổng RJ45).
- Cổng USB-B (3 trong 1) trình chiếu hình ảnh, âm thanh và điều khiển từ xa.
- Tự động cân chỉnh vuông màn hình.
- Hỗ trợ đa ngôn ngữ.
- Kích thước: 314.5 x 344 x 94 mm.
- Trọng lượng: 3.7kg.
Đặc tính kỹ thuật
Projection Technology
|
RGB liquid crystal shutter projection system (3LCD)
|
LCD Size
|
0.55 inch with MLA (D8)
|
Native Resolution
|
XGA
|
Projection Lens
|
Type
|
No Optical Zoom / Focus (Manual)
|
F-Number
|
1.60
|
Focal Length
|
6.4 mm
|
Zoom Ratio
|
1.0 - 1.35 (Digital Zoom)
|
Throw Ratio
|
0.55 - 0.74 (Wide - Tele)
|
Lamp
|
Type
|
215W UHE
|
Life (Normal/Eco)
|
5,000 hours / 10,000 hours
|
Screen Size (Projected Distance)
|
Zoom: Wide
|
50 inch - 108 inch [0.54 - 1.22 m]
|
Zoom: Tele
|
37 inch - 80 inch [0.54 - 1.22 m]
|
Brightness
|
White Light Output (Normal / Eco)
|
3,200lm / 1,800lm
|
Colour Light Output (Normal)
|
3,200lm
|
Contrast Ratio
|
16,000:1
|
Internal Speaker(s)
|
Sound Output
|
16W Monaural
|
Keystone Correction
|
|
Vertical / Horizontal
|
±15º / ±15º
|
Connectivity
|
Analog RGB Input
|
|
D-Sub 15 pin
|
2 (Blue)
|
Composite
|
RCA x 1 (Yellow)
|
S-Video
|
1
|
Digital Input
|
HDMI
|
1
|
Audio Input
|
RCA (White/Red)
|
Yes
|
Stereo Mini Jack
|
2
|
USB Input
|
USB Type A
|
1 (for USB Memory, USB Document Camera, Wireless LAN, Firmware Update, Copy OSD Settings)
|
USB Type B
|
1 (for USB Display, Mouse, K/B, Control, Firmware Update, Copy OSD Settings)
|
Control I/O
|
RS-232C
|
D-Sub 9pin x 1
|
Video Output
|
Monitor Out
|
1
|
Audio Output
|
Stereo Mini Jack
|
1
|
Mic Input
|
Stereo Mini Jack
|
1
|
Network
|
Wired LAN
|
RJ45 x 1 (100Mbps)
|
Wireless
|
Optional (ELPAP07)
|
Operating Altitude
|
0 - 3,000 m
|
Direct Power On / Off
|
Yes
|
Start-Up Period
|
Less than 7 seconds, Warm-up period: 30 seconds
|
Cool Down Period
|
Instant Off
|
Power Supply Voltage
|
100 - 240 VAC ±10%, 50/60 Hz
|
Lamp On (Normal / Eco)
|
298W / 221W
|
