Projector type |
LCD projectors |
LCD panel |
Panel size |
25.4 mm (1.0 in) diagonal (16:10 aspect ratio) |
Display method |
Transparent LCD panel (x 3, R/G/B) |
Drive method |
Active matrix method |
Pixels |
2,304,000 (1920 x 1200) pixels x 3 |
Light source |
Laser diodes |
Light output |
16,000 lm |
Time until light output declines to 50% |
20,000 hours (NORMAL) |
Resolution |
1920 x 1200 pixels |
Contrast ratio |
3,000,000:1 (Full On/Full Off) |
Screen size (diagonal) |
2.03–12.7 m (80–500 in), 16:10 aspect ratio |
Center-to-corner zone ratio |
85% |
Lens |
Optional powered zoom lenses |
Lens shift |
Vertical (from center of screen) |
±60 % (±40 % with ET-EMW200, ±50 % with ET-EMW300) (powered) |
Horizontal (from center of screen) |
±20 % (±19 % with ET-EMW200) (powered) |
Keystone correction range |
Vertical: ±40° (±14° with ET-EMW200/ET-EMW300, ±22° with ET-EMW400/ET-EMW500), Horizontal: ±15° (±8° with ET-EMW200/ET-EMW300) |
Installation |
Ceiling/floor, front/rear, free 360-degree installation |
Terminals |
SDI IN |
BNC x 1: 3G/HD-SDI input |
HDMI IN |
HDMI 19-pin x 1 (Compatible with HDCP 2.2, Deep Color, 4K/60p signal input) |
DVI-D IN |
DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only) |
RGB IN |
D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
SERIAL/MULTI PROJECTOR SYNC IN |
D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
SERIAL/MULTI PROJECTOR SYNC OUT |
D-sub 9-pin (male) x 1 for link control (RS-232C compliant) |
REMOTE 1 IN |
D-sub 9-pin (female) × 1 for external control (parallel) |
REMOTE 2 IN |
M3 x 1 for wired remote control |
REMOTE 2 OUT |
M3 x 1 for link control (for wired remote control) |
DIGITAL LINK |
RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT™ compliant), 100Base-TX (Compatible with PJLink [Class 2], Art-Net, HDCP 2.2, Deep Color, 4K/60p signal input) |
LAN |
RJ-45 x 1 for network connection, 10Base-T, 100Base-TX (Compatible with PJLink [Class 2], Art-Net) |
DC OUT |
USB Connector (Type A) x 1 (Output 5 V/2 A) |
Power supply |
AC 100–240V, 50/60 Hz |
Power consumption |
1,050 W |
Cabinet materials |
Molded plastic |
Filter |
Included (Estimated maintenance time: approx. 20,000 hours) |
Operation noise |
38 dB (NORMAL) / 32 dB (Quiet) |
Dimensions (W x H x D) |
650 x 185 x 440 mm (25 19/32˝x 7 9/32˝ x 17 5/16˝)
(Without lens) (Not including protruding parts) |
Weight |
Approx. 22.3 kg (49.2 lbs) |
